Full Features
Driver Convenience
- Area view
- Bluetooth system
- Columbus satellite navigation with 9.2" touchscreen, integrated Wi-Fi, web radio
- e call+
- ECO Stop/start function
- Exterior temperature indicator
- Progressive steering
- Smartlink wireless for apple carplay and wired for android auto
- Speed limiter
- USB C Port x 2 in front centre console
- Virtual Cockpit - 10.25" digital display
- Wireless charging
Entertainment
- Canton sound system
- DAB Digital radio
Exterior Features
- Aero front windscreen wipers with intermittent function
- Aero rear window wiper
- Auto dimming rear view mirror
- Black wheel arch surrounds
- Body colour bumpers
- Body colour door mirrors and handles
- Body colour door panels
- Chrome front grille
- Chrome roof rails with chrome window surround
- Electric front and rear windows
- Extended rear spoiler with finlets in gloss black
- Front fog lights
- Full LED matrix headlights with AFS (adaptive front light system), cornering function and AWL (all weather lighting system)
- Headlight washers
- Heated rear window
- Invisible tailpipe
- L&K front and rear bumpers including lower rear chrome strip
- LED daytime running lights
- LED rear fog light
- LED third brake light in rear spoiler
- Off-road style lower front bumper element
- Panoramic sunroof
- Privacy glass
- Rain and light sensors
- Rear LED lights (high functionality) with welcome effect and dynamic indicators
- Safety reflectors on front and rear doors
- Window control switches with black trim
- Without engine designation
Interior Features
- 12V socket in boot
- 2 rails with 2 hooks
- 4 foldable roof handles with rear coat hooks
- 60:40 foldable rear seat with sliding adjustment and backrest angle adjustment
- Aluminium pedals
- Bottle holders in door panel in the 1.5 litre front and 1 litre rear
- Cargo storage compartments
- Chrome headlight control button
- Chrome interior door handles
- Coat hooks on B pillar
- Covered storage compartment on driver side
- Decorative door sills in the front and rear
- Front centre armrest with storage compartment, cup holder and 12V socket
- Front courtesy lights
- Gear shift lever with chrome frame and black gloss insert
- Grey stitching in front and rear armrests and door armrests + door inserts
- Height adjustable front headrests
- Illuminated and cooled glovebox
- Illuminated luggage compartment
- Isofix child seat fittings in outer rear seats with top tether
- Manually adjustable steering column
- Net programme in boot (1x horizontal Net, 2x vertical Nets)
- Overhead glasses storage compartment
- Pollen filter
- Rear centre armrest with cupholders
- Sliding trunk cover
- Small Bags on the inner sides of the front backrests
- Sunvisors with illuminated vanity mirrors
- Three rear height adjustable headrests
- Ticket holder on A Pillar
- Umbrella in door panel
- Variable boot floor
Packs
- LED Interior light pack - Kodiaq
Passive Safety
- Auto door release and activation of warning lights
- Driver and front passenger airbag with knee airbag and front passenger airbag deactivation
- Electronic parking brake with hill start assist
- Emergency rear braking signal
- ESC (incl. ABS+MSR+ASR+EDS+HBA+DSR+RBS+MKB)
- Front assist with autonomous emergency braking
- Front side airbags with curtain airbags
- Fuel cut off safety device
- Height adjustable front 3 point seatbelts + pretensioners
- Hill hold control
- Rear disc brakes
- Safety vest holder in door
- Seat belt reminder for all seats
- Tailgate unlocking from outside
- Three point rear seat belts
- Two tone horn
- Tyre pressure monitor
Security
- Alarm with interior monitoring and tilt sensor with safe function
- Anti-theft wheel bolts
- Immobiliser
- Keyless entry and start system (KESSY)
- Remote central locking with 2 keys
Trim
- Grey stitching in dashboard
- Piano black decorative inserts
- Plaquette L&K front fenders
Wheels
- Temporary spare wheel (space saver)
Technical Specifications
Emissions - ICE
- CO2 (g/km) 138
- HC Not Available
- NOx 0.037
- Particles 0.0001
- Standard Euro Emissions EURO 6
- WLTP - CO2 (g/km) - Comb 163
- WLTP - CO2 (g/km) - Comb - TEH 166
- WLTP - CO2 (g/km) - Comb - TEL 163
- WLTP - CO2 (g/km) - Extra High - TEH 171
- WLTP - CO2 (g/km) - Extra High - TEL 168
- WLTP - CO2 (g/km) - High - TEH 143
- WLTP - CO2 (g/km) - High - TEL 141
- WLTP - CO2 (g/km) - Low - TEH 212
- WLTP - CO2 (g/km) - Low - TEL 208
- WLTP - CO2 (g/km) - Medium - TEH 163
- WLTP - CO2 (g/km) - Medium - TEL 160
Engine and Drive Train
- Camshaft DOHC
- Catalytic Convertor Yes
- CC 1968
- Compression Ratio 16.0:1
- Cylinder Layout IN-LINE
- Cylinders 4
- Cylinders - Bore (mm) 81.0
- Cylinders - Stroke (mm) 95.5
- Engine Layout FRONT TRANSVERSE
- Fuel Delivery COMMON RAIL
- Gears 7 SPEED
- Number of Valves 16
- Transmission AUTO
Fuel Consumption - ICE
- EC Combined (mpg) 54.3
- EC Directive 1999/100/EC Applies No
- EC Extra Urban (mpg) 60.1
- EC Urban (mpg) 45.6
- WLTP - FC (l/100km) - Comb - TEH 6.3
- WLTP - FC (l/100km) - Comb - TEL 6.2
- WLTP - FC (l/100km) - Extra High - TEH 6.5
- WLTP - MPG - Low 6.4
- WLTP - FC (l/100km) - High - TEH 5.5
- WLTP - FC (l/100km) - High - TEL 5.4
- WLTP - FC (l/100km) - Low - TEH 8.1
- WLTP - MPG - Extra High 7.9
- WLTP - MPG - High 6.2
- WLTP - FC (l/100km) - Medium - TEL 6.1
- WLTP - MPG - Comb - TEH 44.8
- WLTP - MPG - Comb - TEL 45.6
- WLTP - MPG - Extra High - TEH 43.5
- WLTP - MPG - Extra High - TEL 44.1
- WLTP - MPG - High - TEH 51.4
- WLTP - MPG - High - TEL 52.3
- WLTP - MPG - Low - TEH 34.9
- WLTP - MPG - Low - TEL 35.8
- WLTP - MPG - Medium - TEH 45.6
- WLTP - MPG - Medium - TEL 46.3
General
- AdBlue Yes
- Alternative Fuel Qualifying No
- Badge Engine CC 2.0
- Badge Power 150
- Based On ID Not Available
- Coin Description TDI 4X4
- Coin Series Laurin + Klement
- Generation Mark 1
- Insurance Group 1 - 50 Effective January 07 22E
- Manufacturers Corrosion Perforation Guarantee - Years 12
- Manufacturers Paintwork Guarantee - Years 2
- Did at least one aspect of this vehicle's safety give cause for concern? No
- Special Edition No
- Special Order No
- Standard manufacturers warranty - Mileage 60000
- Standard manufacturers warranty - Years 3
- Timing Belt Interval Mileage 140000
- Vehicle Homologation Class M1
Performance
- 0 to 62 mph (secs) 9.8
- Engine Power - BHP 150
- Engine Power - KW 110
- Engine Power - RPM 3000
- Engine Torque - LBS.FT 266
- Engine Torque - MKG 36.7
- Engine Torque - NM 360
- Engine Torque - RPM 1600
- Top Speed 124
Test Cycles
- Emissions Test Cycle WLTP
- RDE Certification Level RDE 2
Tyres
- Alloys? Yes
- Space Saver? Yes
- Tyre Size Front 235/50 R19
- Tyre Size Rear 235/50 R19
- Tyre Size Spare SPACE SAVER
- Wheel Style SIRIUS
- Wheel Type 19" ALLOY
Vehicle Dimensions
- Height 1666
- Height (including roof rails) 1686
- Length 4699
- Wheelbase 2790
- Width 1882
- Width (including mirrors) 2087
Weight and Capacities
- Fuel Tank Capacity (Litres) 61
- Gross Vehicle Weight 2550
- Luggage Capacity (Seats Down) 2005
- Luggage Capacity (Seats Up) 270
- Max. Loading Weight 727
- Max. Roof Load 75
- Max. Towing Weight - Braked 2000
- Max. Towing Weight - Unbraked 750
- Minimum Kerbweight 1823
- No. of Seats 7
- Turning Circle - Kerb to Kerb 11.6
